圆形中两脚轻触开关6×6×H
规格:6×6×H
型号:GT-TC141X-HXXX-LX
包装:1000/卷
圆形轻触开关6*6柄长4.3、4.5、5.0mm;动作力:100、160、250gf。
声明:有关于产品的规格、参数、寿命、工作温度、手感、防水等级等数据,只代表品赞电子内部的测试结果,如需详细测试方式,请联系品赞业务人员。
Specification
FUNCTION: Momentary action
CONTACT ARRANGEMENT: 1 make contact = SPST, N.O.
Electrical
MAXIMUM VOLTAGE: 15 VDC
MAXIMUM CURRENT DC: 20 mA
DIELECTRIC STRENGTH: 250 VA C (1mn)
CONTACT RESISTANCE: ≤ 100 mΩ
INSULATION RESISTANCE: ≥ 100 MΩ
BOUNCE TIME: ≤ 10 ms
SWITCH TRAVRL:0.25±0.1mm
Environmental
OPERATING TEMPERATURE: -40˚C to 85˚C
Molde code:
